Thiết Bị Đo Và Ghi Đa Năng Hioki MR8740

MEMORY HiCORDER HIOKI MR8740

Single-device Solution for Waveform Recording and Generation, High-speed 54-channel/Isolated Multi-channel System Recorders (rack-mounted)

Max. Number of channels	[Block I] 32 ch analog + 8 ch logic, or 29 ch analog + 56 ch logic (when used with built-in logic input + plug-in logic unit 8973 × 3) [Block II] 22 ch analog + 8 ch logic, or 19 ch analog + 56 ch logic (when used with built-in logic input + plug-in logic unit 8973 × 3)
Number of slots	[Block I] 16 slots (Max. 16) [Block II] 11 slots (Max. 11)[Limitation on number of slots] when using the Current Unit 8971: Max. 4, When using the Logic Unit 8973: [Block I] Max. 3; cannot use slots 9 to 16 [Block II] Max. 3; cannot use slots 9 to 11
Number of logic channels	[Block I] 8 ch logic (Logic probe terminal GND share a common GND with chassis. ) [Block II] 8 ch logic (Logic probe terminal GND share a common GND with chassis. )[Limitation on using built-in logic input] applies to both Block I and Block II (with logic measurement ON) – Measurement resolution on slots 1 and 2 is limited up to 12 bits – Cannot use Frequency Unit 8970 on slots 1 and 2 – When using the DVM Unit MR8990 on slots 1 or 2: cannot use built-in logic input
Measurement ranges (20 div full scale)	5 mV to 20 V/div, 12 ranges, resolution : 1/100 of range (when using 8966) 5 mV to 50 V/div, 5 ranges, resolution : 1/50,000 of range (when using MR8990)
Max. allowable input	400 V DC (when using 8966; upper limit voltage that can be applied between input terminals without damage)
Max. rated voltage to earth	300 V AC/DC (input and instrument are isolated; between input channels and chassis; upper limit voltage that can be applied between input channels without damage)
Frequency characteristics	DC to 5 MHz (-3 dB, when using 8966)
Time axis (MEMORY operation)	5 µs to 5 min/div; 26 ranges; time axis resolution: 100 points/div; time axis expansion: 3 stages from ×2 to ×10; compression: 13 stages from 1/2 to 1/20,000
Measurement functions	Memory (high-speed recording), FFT
Memory capacity	16 MW/ch (fixed), total of 864 MW installed
Removable storage	USB memory stick (USB 2.0)
Display	None (1 digital DVI terminal per block, 800 × 600 dots)
External interfaces	[LAN] 100Base-TX (DHCP and DNS support, FTP server, HTTP server) [USB] USB 2.0 Series A receptacle × 2 (mouse operation)
Power supply	100 to 240 V AC, 50/60 Hz (250 VA max.)
Dimensions and mass	426 mm (16.77 in) W × 177 mm (6.97 in) H × 505 mm (19.88 in) D, 10.8 kg (381.0 oz) (main unit only)
Accessories Hioki MR8740	Instruction manual × 1, Application disk (Wave viewer Wv, Communication commands table) × 1, Power cord × 1
